Introduction to Faster Payment System (UK FPS)

The diagram below shows the system implementation context.

FPS handles the following payments:

Temenos Payments Solution supports the following UK FPS message types:

Temenos Payment Solution offers a payment capture page for the following FPS types:

• SIP
• FDP
• SOP

UK FPS offers a special service known as Account Switching Service (CASS), which allows the banks to register account redirection information within the CI. If redirection is configured for an FPS (received for an account):

• CI replaces the account with the redirect account information and forwards the payment to the beneficiary bank.
The beneficiary bank is unaware of the account redirection available in the payment, and processes it as a regular inward payment.
• CI advices the redirected account information to the originating bank in PSR. The originating bank updates its payment information with the redirected beneficiary account details.

The following deployment options are available when the TPH supports receiving account redirection:

The bank may not credit the beneficiary immediately on the receipt of an inward payment in FPS scheme. This depends on the following:

• Own technical infrastructure
• Arrangements with the originating bank
• Account with institution bank

For FPS scheme, the beneficiary bank instructs the originating bank about the time frame for credit availability. This is done using qualifier codes in PSR with the following options:

TPH offers instant credit availability, when it operates with Temenos Core Banking (Transact) as an Account Management System (AMS) or an external core banking system.

1. If the system is unavailable to perform real time postings (due to maintenance), TPH needs to be intimated.
2. If intimated, TPH continues to accept FPS but responds with a ‘Delayed Credits’ qualifier code.

TPH advices delayed credit availability by using appropriate qualifier code as given below:

TPH can change the categorisation at project implementation level, based on the bank’s requirements. It involves:

• Prioritisation of SIP during its processing (real time payments).
• Processing of SOP and FDP with lower priority (near-real time payments).

FPS has the following cut-off definitions:

CI sends scheme reversals to the receiving bank when PSR is not received for a previously sent payment request. Scheme reversals are applicable only for synchronous mode of processing. CI requires a response to a payment request within the predefined time. CI initiates scheme reversal when the session times out waiting for a PSR. On receipt of scheme reversal, the receiving bank needs to do the following:

1. Mark the original payment as reversed.
2. Undo any bookings previously made against the original payment.
3. Return a positive acknowledgement.

If the original payment is not found, the scheme reversal is recorded with no specific processing.

Scheme return has return code instructed in PSR by the beneficiary bank with no associated SLAs in CI. CI generates and:

• Sends scheme return to the submitting bank (debtor bank), when the beneficiary bank rejects the previously processed SOP or FDP. The submitting bank then credits the payment initiator with the value of the return payment.
• Returns the scheme as a new payment by its own right as original payment is already settled in CI by the sending bank. The sending bank processes the payment independent of original payment, and always returns acceptance to CI (that is, scheme return payment cannot be returned).

Sometimes originating bank may want to resend a payment, if status response is not received in time for the original payment message.

• When the originating bank sends a credit transfer payment, it usually receives a response (as a status message) from clearing in real time.
• If the originating bank does not receive a status response from clearing, it resends the payment message after waiting for certain time (configured in TPH). The system does not create another payment for this purpose.
• When no response is received from clearing for a payment, the payment is resent to FPS at pre-defined intervals (in seconds) based on the configuration.

If the clearing does not receive status response from the beneficiary bank, it sends a repeat payment message to the bank. The repeat payment message received from clearing, is identified as a ‘repeat’ by TPH. This can happen if:

• PSR sent by the beneficiary bank does not reach the clearing, due to some technical issues.
• The beneficiary bank did not send the PSR to clearing, due to some technical issues.

An immediate clearing status message is sent depending on whether the original payment is successful or failed.

• Audit trail of the original payment is updated with the details of the repeat response sent to clearing.
• If original payment is not found, then the repeat payment is processed as a new payment (regular processing of inward FPS).

When there is a change, CI sends status update messages to all FPS participants. The possible statuses are:

• Active
• Suspended

Status updates are received as Unsolicited Message (USM). USM is an 8583 formatted message. This is converted to Temenos native message (OFSML) in the bank’s gateway. To know more, refer to see Interfaces. PO application or TPH validates the service status while a payment is manually initiated. If clearing status is ‘Suspended’, TPH:

1. Triggers an error disallowing initiation.
2. Processes outgoing or redirected UK FPS in STP mode.
3. Validates the payment during payment processing and parks the payment in Repair queue.

DCA payments are received as individual payments (pacs.008) from FPS CI. TPH accepts and processes these regular incoming payments with exception that FPS type is recorded as 50.

Outward Processing of UK FPS

Outward processing of SIP, FDP and SOP involves two payment modules.

• PO application
• TPH

The flowchart given below shows the sequence of processing activities involved in the payment.

Activity	Description
Manual capture of SIP	Captures a FPS SIP from PO application. Validates mandatory and non-mandatory fields on submission and displays an error (if any).
Automatic initiation of SOP	Temenos Transact SOD process automatically initiates a SOP on the processing date. PO application receives SO for further processing and distribution to FPS CI.
Business validations – The system performs the following business validations on the payment. If any of the validations fail, SIP are parked in Repair queue for user action. SOP are cancelled automatically.
Account validations	Validates debit account, if it is present in Temenos Transact. Validates the IBAN structure, if the user enters debtor or beneficiary IBAN. The system fetches debtor IBAN from Temenos Transact database, if not present in the instructions.
Bank code validations	Validates the BIC, if the user enters the creditor bank BIC. Derives the BIC based on IBAN (if IBAN is available), if the user does not enter the creditor bank BIC.
CI service status	Validates if the FPS CI service status is ‘Suspended’.
Duplicate checks	Duplicate checks are not performed during initiation (as this is not mandated by scheme rules). The bank can configure as per specific requirements.
Transaction limit	Validates the FPS transaction limit against payment amount.
Reachability check	Validates if the beneficiary bank (sort code) is reachable directly or indirectly.
Payment simulation applicable only when: A payment is manually captured using PO application or Customer facing channels interact with PO application. During the simulation, the system calculates the following: Applicable charges Value date Exchange rate (if FX involved) The user submits or abandons the payment based on the above. Simulation can be enabled when PO application is operating with TPH as payment system. PO application can be configured to perform basic simulation when installed with a non-Temenos payment system. This is limited to configuration of charges and value date calculations. Clearing or customer specific validations are not performed by PO application. Simulation involves the following steps:
Account restrictions	The system validates the following: Posting restrictions on debit account Posting restrictions on credit account (if the account is in the same bank) If the account has restrictions, cancel the payment order (if manually captured) or send negative PSR.
Cut-off check	FPS is 24x7 system and operates with no clearing cut-off. The payment is therefore not validated for cut-offs.
Dates calculation	The following fields are assigned the same date as the current system date. Acceptance Date Time Execution Date Credit Value Date Debit Date
Charge calculation	The system calculates all the applicable charges for the payment (as configured).
Balance check	The system performs balance check on debtor account for total value of payment amount and charges. If account does not have sufficient balance, then the system cancels the payment order.
Once the user submits the payment post simulation, the payment awaits Supervisor approval. If approved, the payment is moved for further processing. If rejected, the payment can be modified and resubmitted for approval. SOP are automated payments and are not subject to simulation.
Fraud check	If configured, the system invokes fraud check. A fraud check request is sent to Fraud Check Engine and the status of the payment is updated when fraud check response is received. Payment may be set to Cancelled, or Continue Processing based on the configuration.
Send payment to payment system	Payment order is sent to payment system for execution. If the payment system is TPH, then the transfer is embedded between PO application and TPH. If the payment system is third party (not Temenos), then an payment initiation message (pain.001) is generated by PO application. The payment system acknowledges the receipt of the payment initiation message in both the cases and payment is in ‘Placed’ status in PO application.
Time stamping the payment	FPS does not have timestamp as SLA is not validated (based on payment initiation time point). However, payments are still timestamped in TPH as it is used in future developments for generating duplicate payment requests in case of exception scenarios. FPS runs an internal counter from the time it receives the payment from the originating bank to the time it sends a PSR to the originating bank. However, this is not based on any timestamp information in the payment file.
Filtering	TPH performs filtering of payments, if configured. This is a bank specific requirement and handled during implementation.
Routing	The payment is routed to UK FPS clearing channel, which is configured to route to FPS CI (by using IIB). Clearing channel determines the message type (FPS pacs.008).
Charge calculation	TPH calculates the charges applicable for the processed payment. Calculated charges are displayed as debit side charges (against the payment) after this activity. The charges calculated are same as the calculations done during simulation. If charge configuration is changed after the simulation activity, then the calculation is different. All fees including FPS transaction fees (if any) are set as per bank specific requirements during implementation.
Funds reservation	This activity reserves funds on the debit account. This is a bank specific requirement to be done during implementation. To reserve funds, configure Source, Account Type and Message Type in PP.BALANCE.CHECK.REQUIRED table. If AMS is Temenos Transact, then TPH performs funds reservation in embedded mode. If AMS is external, then it generates fund reservation request in a standard XML format and accepts response from the external system.
Debit posting	Debtor’s account is debited with payment amount and any charges are borne by the customer. If posting fails due to insufficient funds, the payment is cancelled. If AMS is Temenos Transact, then TPH performs debit posting in embedded mode. If the AMS is external, then it generates posting request in a standard XML format and accepts response from the external system.
Outward payment generation	IIB generates payment request and it complies to FPS schema defined in ’pacs.008.001.06 FIToFICustomerCreditTransferV06 pain.001’. Payment is parked in ‘Awaiting PSR’ status.

Inward Processing of UK FPS





Activity	Description
FPS received from CI	TPH receives an inward payment from CI in the following scenarios: Processes SIP request and sends a payment response in real time. Processes SOP request (FPS settled) and sends the response in near-real time or same day. TPH processes both the payment types using the same workflow.
Business validations – The following business validations are performed when CI receives a pacs.008.
Duplicate check	Validates if FPS ID is duplicated within the last 7 business days (configurable). FPID is a combination of following fields in payment request. Sending FPS Institution Currency Date Sent Payment Type Code Transaction Reference Number (TRN) Message ID or TXID of pacs.008 is not checked for duplicate. Message ID is different from the one sent by the originating bank to FPS CI.
Account validation	Validates the beneficiary account: Beneficiary sort code or account number unknown Beneficiary account closed Beneficiary account stopped Beneficiary account name does not match with the beneficiary account number (not performed for FPS) Account is not in the quoted currency
Bank code validation	NA
Account restrictions	Validates restriction on beneficiary account Account does not permit credits
Generate PSR (failed)	If any of the business validation fails, the system generates a PSR in FPS pacs.002** format (with response status as failed, and an appropriate FPS error code).
Calculate charges	In case of charge code SHA, any applicable charges are calculated and applied on the payment.
Beneficiary credit posting	Beneficiary is booked with payment amount minus any applicable charges with value date as instructed in the Interbank Settlement Date.
Generate PSR	The system generates a PSR in FPS pacs.002** format with response status as Success, and an appropriate FPS qualifier code. The qualifier code is always set at ‘000’ by TPH for SIP and SOP, indicating that the credit is made to the beneficiary in real time. The solution can be enhanced in future to provide pending confirmations when Core Banking system is down.
